There was only one channel to buy DELL's computer in the early years. That was Shanghang.com's direct order. Later, Dell opened sales channels for dealers in China, and also bought DELL computers in traditional stores.
Precision is DELL's mobile workstation series, belonging to the top line of the entire series, working with Precision, Alienware games, two-pronged positioning is more accurate.
With the demand of work, the idea was to get into the graphical mobile workstation. The original ThinkPad P50 was actually the right one, but later it was found that the M5510's volume and weight was a lot thinner and lighter than the P50. A lot of convenience.
Then the next question is which channel to start with. Everyone knows that DELL's top line, BNM's pricing has always been cold, so many friends will choose Haitao, and then because DELL has special care for the top series, you can It is more convenient to transfer insurance to China for warranty. Therefore, at the beginning, the United States Bank was also considered, but it seems that it would be more appropriate if the prices of official turnaround machines were appropriate. If it is a brand-new machine, coupled with the cost of the reinsurance warranty, as well as the toss and frustrations of finding a purchasing agency, it is determined to choose the most worry-free BNM.
After the channel was settled, it began to tangled in the configuration, and finally set the two configurations (the following bold fonts are the main differences):
National Bank of the 5510-4K3, specific configuration: E3/4K screen / M1000M 2G graphics card / 8G memory / 256G solid state +1T mechanical hard drive / 56 Watt small battery / WIN Home
State Bank of the 5510-4K5, specific configuration: E3/4K screen / M1000M 2G graphics card / 16G memory / 1T solid state / 84 Watt small battery / WIN Pro
5510-4K3 machine is a single from the dealer orders, the country's version of the 5510-4K5 top is DELL official orders sent directly through the Kerry Chase. Both machines are labeled with the “China Energy Efficiency Label†that is unique to China’s licensed packaging, and it is used to further verify the status of the Bank of China.
First look at the top with the factory date is July 29, very fresh.
The dealer orders the machine is June 1, the backlog of two months, this is still understandable, after all, the price is not low because of the slow liquidity.
Then start out of the box, take the top match to be a demonstration.
After unpacking, you can see that there are three accessories that come with the cable to the interface, the 130W power adapter, and the power cord. Of course there is a big main computer box.
The reason that the original machine is estimated to be thin and light, the use of network cable can only pass through the latest USB-C switch cable port, thanks to the current work environment full of wireless.
Specially opened close-up power cord, the same type of font printed above, is the original line of the original machine, this can be used to identify friends through Tao Tao Tao line to identify the reference.
The supplied power adapter is in the category of a mobile workstation and is considered small. On the right is Sony's latest mobile phone XP as a reference. About 400g in weight, if compared with the adapter of the Superband, it is more important, but it is the workstation adapter, ah, it is already lighter than the P50, so comprehensively speaking, it is still acceptable.
Adapters, power cords, including cable converters, three-pieces are needed to carry on weekdays, and the overall fit is light and portable. The backpack is an upgraded version of ELECOM off toco S028. With an increase in capacity, the 15-inch M5510 is just right. Traveling will not be too burdensome.
Next, open the black box and the main body of the M5510 is displayed.
There is a nameplate on the back, imprinted with "DELL Precision 5510", which explains its identity.
State Bank top version, directly configure the WIN10 Professional Edition, the language of course will be Chinese, this one, but the relatively low-level configuration, replaced by the home version, although for most people use is not bad, but If not, it will always feel strange to use.
The groove of the box, also comes with two manuals, although not important. But here to explain, from the dealer's order 5510-K3 version does not even have these two manuals! Therefore, Haitao's friends should pay special attention to it. If not sure, there are some problems?
Then, both machines are out of the box, and the other one is not repeated. It is estimated that no one wants to read it again.
The two M5510s are out of the box at the same time. This is rare. In addition to the configuration differences, even an interesting phenomenon has been discovered! After the machine is turned on the C side, the carbon fiber texture on the top with the 5510-K5 is lighter than the 5510-K3, which is less obvious. This is how it happened, DELL's entire assembly line down, is it also different distribution points at the top, it is not estimated, is the problem of non-uniform material standardization, right? It is estimated that DELL also did not expect that there are even two M5510s that can be unpacked at the same time to contrast the tossing master.
If you don't look for it, you'd like to compare it with other machines at the top of the box. Therefore, the difference between the machines and the series is not obvious. However, this time, the same model is used for double-opening. What's the problem? Now come talk about the second interesting difference! By contrast, the screen is the same 4K screen, the brightness of all the highest tone, even the top version than the 5510-K3 version of the visual inspection brightness at least one file! As you can see, the top version is on the left and the brightness is obviously higher. Can only say DELL factory standard quality control? Where are you, don't know how to say it again. However, if you don't compare this, the average person simply doesn't know what's the difference between the machines on your hands.
Next, start to configure the sun, the following left is the 5510-K5 top with the right is 5510-K3 configuration
RAM
5510-K5 top configuration 8G+8G DDR4 2133MHz, a total of 16G of memory, brand SK Hynix. The machine can support up to 32G of memory. Because there are only two slots, the upgrade can only be replaced. The current 16G is sufficient for the time being.
5510-K3 configuration 4G + 4G DDR4 2133MHz, a total of 8G of memory, the brand is Samsung, this configuration 8G memory is more headache, 8G generally only marginally, so it will choose to replace the replacement, but 4G sliver replacement is not worth Several silver.
hard disk
5510-K5 top allocation configuration 1T NVMe standard M2, the brand is Samsung, it should be PM951, but unfortunately not a more advanced SM951, can only say DELL stingy, due to the need for capacity, too lazy to toss directly on the 1T version, the actual use Feeling, the speed is actually fast enough, but not every day to run points, sending oversized files all the time, or enough, only to comfort themselves.
The 510-K3 is configured with 256G NVMe standard M2, branded Samsung and PM951. In addition, there is also a block of 1T mechanical hard drive, brand Hitachi.
battery
5510-K5 top configuration with 84 watts, commonly known as the large battery version, the actual experience down, working hours in 5-6 hours, and the official nominal time difference, may be the station's high-strength tasks will consume more power it.
5510-K5 top configuration configuration 56 watts, commonly known as the small battery version, use often 3-4 hours or so, feel suddenly returned to the book experience N years ago, go out with the adapter must be brought.
The above are two different configurations, the biggest difference, but also many friends choose when, in addition to CPU, 4K screen, the most tangled part, I do not tangled, so the two-machine full income, also found two interesting issues Point of experience! ?
Two narrow borders, how can I play? You can look at the picture like this, haha.
Small Eggs: How DELL's original liner fits, is the docking station worth buying? ... 4K Sharp screen stunning? Leave a suspense next time.
Concluding remarks: Unpacking has come to an end. Follow-up will continue with several series of codewords. Plan: 2. Experiencing articles, comparing machine feelings with other models; 3. Accessories; About the original factory liner, docking station Other sharing; 4. Software articles: What software can be used on the 4K screen, how to share the effect.
